UGT-E4-CO Carbon Monoxide Gas Sensor

UGT-E4-CO Carbon Monoxide Gas Sensor

product overview

The UGT-E4-CO carbon monoxide gas detection sensor is a constant potential electrolytic sensor. Carbon monoxide and oxygen undergo corresponding oxidation-reduction reactions on the working electrode and the counter electrode, respectively, and release charges to form a current. The magnitude of the generated current is proportional to the concentration of carbon monoxide. By testing the magnitude of the current, the concentration of carbon monoxide can be determined.

Performance characteristics

·High precision, long lifespan

·Fast response speed, fast return to zero

·Low power consumption, high sensitivity

·Wide linear range, strong anti-interference ability

·Excellent repeatability and stability

·Numerous application fields

·Small size, high cost-effectiveness

Specification

Detecting gas carbon monoxide

Detection range 0-1000PPM

Maximum load concentration 2000PPM

Sensitivity 80 ± 20nA/PPM

Resolution of 1PPM

Zero drift ± 2PPM

Linearity and linearity, regression coefficient R ²=0.999

Repetitive 1% output signal

Long term stability<2% signal/month

Response time T90<25s

Technical principle: electrochemistry

Service life 2-3 years (in clean air)

Weight 4.8g

Shelf life of 1 year

work environment

Working temperature -30~+50 ℃

Working humidity 15-90% RH (non condensing)

Work pressure 90-110Kpa

Bias voltage 0

Load resistance 5-30 Ω

Application Fields

Instrumentation

Steel and Chemical Industry

industrial safety

Gas leakage

air purification
